Ø55 I Ø65 I DALI TW

L08065 Spotlight    IP44

Aluminium extrusion and powder coating housing. multiple installations. -Flicker-Free- High Definition optical lenses in thermoplastic material. -Uniform distribution. -Specialised optics and optical filters can be ordered.-

The spot was designed to meet multiple lighting requirements,an ideal solution for accent lighting in residential, hospitality or commercial spaces.The range features low to high lumen packages, narrow to wide beam options,standard or specific LED colours, recessed to surface mounted and track applications or suspendent, different colour finishes and combinations,and can be equipped with multiple light refining accessories. better light comfort through lens optics,improved LED colour consistency and new perspectives with Tunable White and Soft Dim. (D55xH180mm 10W DALI) (D55xH240mm 10W DALI TW) (D65xH200mm 12W DALI) (D65xH240mm 12W DALI TW)

TECHICAL DATA

  • 800-1000lm
  • Built-in Driver
  • Aluminium lighting fixture, powder coated.
  • Flicker Free CRI90+ UGR<16
  • DALI I Triac I 0/1-10V I Tunable white dimming
  • Ceiling Suspended I Ceiling Mounted installation.
  • Famous brand LED chips

Product is Europe Standard & CE Certificate.

INTERIOR LED SUSPENDED SPOTLIGHT

L08065

IP44

CLASS III

Ceiling Suspended I Ceiling Mounted installation.

Standard length of cable 2000mm with quick connector.

ECO Energy Saving Aluminium materials

Eyes friendly CE certificate RoHS standard

Famous brand LED Chips

Triac I 0/1-10V I DALI TW dimmable

Customized color finishing.

Warranty 5 Years

High Definition optical lenses Uniform distribution

Code System Power
W
Output Lumen
lm
Dimension
mm
Cut Hole
mm
Power Supply
mA
L08065-10 10W 800lm
55xH180mm
mm
250mA
L08065-10 10W 800lm
55xH240mm
mm
250mA
L08065-12 12W 1000lm
65xH200mm
mm
300mA
L08065-12 12W 1000lm
65xH240mm
mm
300mA

FEATURES

Built-in Driver Accessoires Beam Angle Color Temperature Finishes
10W   250mA
10W   250mA
12W   300mA
12W   300mA
